Vebe test-(Video-Youtube)

By -
Post a Comment
Read more

Rebound hammer test on concrete-(Video-Youtube)

By -
Script: Rebound hammer is a non-destructive test used to examine the hardened concrete. The principle of the rebound test is based on the rebound of a plunger. The plunger of the rebound hammer is pressed against a concrete surface. The hammer mass will be pushed back and secured to a pin. The impact spring is attached to the hammer mass, so it will be extended with the hammer mass. Then the hammer mass is released. finally, the mass will rebound against the concrete surface. The surface hardness and compressive strength will be correlated with the rebound of the spring controlled mass.    A rebound hammer can be used to evaluate the compressive strength of a concrete member, quality of concrete, and uniformity of concrete. The approximate impact energy required for the rebound of the hammer for different applications is shown in this table. The procedure of conducting the rebound test will begin by the calibration of the test instrument. The rebound hammer will be calibrated against
1 comment
Read more

Bentonite slurry-(Video-Youtube)

By -
Script:   Bentonite slurry is a common type of soil stabilizing liquids. Bentonite used to stabilize the soil for deep foundations such as cast-in-situ piles during the drilling stage. Also, it is commonly used for stabilizing the drilled soil for the diaphragm wall. The bentonite powder is mixed with water. Then it is poured during the drilling of a pile hole to stabilize the soil and prevent the soil from collapse. Bentonite is used where the soil is weak and it is expected to collapse during the drilling of piles or other types of excavations. The bentonite will provide sufficient time to lower the steel reinforcement and cast the concrete while the soil is stable.    The mixing of water with bentonite will produce a gel product when left to stand for sometimes. This product will return quickly to the liquid state when it is in motion. Bentonite mixture should be tested for viscosity, sand content, PH, and density. The density of bentonite can significantly affect bentonite perf
Post a Comment
Read more

Determinate and indeterminate structure-(Video-Youtube)

By -
script: Determinacy, a structure can be called determinate if the equilibrium equation provides enough and sufficient condition for equilibrium. if all forces for a structure can be determined using equilibrium equations only, this structure is determinate, but if the unknown forces are more and cant be determined using equilibrium equations then this structure is indeterminate. in general we can determine if a structure is statically determinate or indeterminate by drawing free body diagram for a structure or part of it and comparing a number of unknown forces and moment component with number of available equation of equilibrium. for coplanar structures, we have  three equilibrium equations, if n is the total number of parts, and r is the number of unknown forces and moment component then. if r = 3 times n, the structure is determinate. and if r  bigger than 3 times n, the structure is indeterminate . statically indeterminate structure cant be solved using equilibrium equations, sol
Post a Comment
Read more

soundness test for cement-(Video-Youtube)

By -
Script: Soundness test conducted in cement to verify that cement will not undergo a destructive expansion after setting. The expansion of restrained concrete members will result in severe tensile stresses that can result in cracking and spalling of casted concrete. The expansion could occur due to the reaction of free lime, magnesia, and calcium sulfate.   Free lime found in the clinker. Free lime inter-crystallized with other compounds, and it tends to expand during the hydration process. The expansion of free lime is more than calcium oxide. Magnesia reacting with water similarly as calcium oxide does. But the crystalline formed due to the reaction of magnesia is deleteriously reactive, so it is unsound. Calcium sulfate can cause destructive expansion. The reaction of calcium sulfate will produce calcium sulfoaluminate (ettringite), which can result in the harmful expansion of cement.  A soundness test will be conducted using La Chatelier's apparatus. For conducting this test, a
1 comment
Read more

Geotechnical investigation of soil-(Video-Youtube)

By -
Post a Comment
Read more

Staggering of rebar overlapping (Video-Youtube)

By -
Post a Comment
Read more
